دستگاه فیوژن فیبر نوری فوجیکورا 62S

دستگاه فیوژن فوجیکورا 62S

دستگاه فیوژن فیبر نوری فوجیکورا 62S

مشخصات فنی فیوژن فیبر نوری فوجیکورا 62S

• Type : Fusion Splicer Fujikura
• Applicable Fibers : Single-mode (G.652 and G.657), Multimode (G.651), DS (G.653), NZDS (G.655)
• Cladding Diameter : 80 μm to 150 μm
• Coating Diameter : 100 μm to 1,000 μm
• Fiber Cleave Length : 5 to 16 mm
• Typical Average Splice Loss : 0.02 dB with SM, 0.01 dB with MM, 0.04 dB with DS, 0.04 dB with NZDS, measured by cut-back method relevant to ITU-T standards
• Splicing Time : ULTRA FAST mode — 6 seconds; SM FAST mode — 7 seconds; SM AUTO mode — 10 seconds with SM fiber
• Arc Calibration Method : Automatic, real-time and by using results of previous splice when in AUTO mode, manual arc calibration function available
• Splicing Modes : 100 preset and user programmable modes
• Splice Loss Estimate : Based upon dual camera core axis alignment data
• Storage of Splice Result : Last 10,000 results stored in the internal memory
• Fiber Display : X or Y, or both X and Y simultaneously. Front or rear monitor display options with automated image orientation
• Magnification : 320X for single X or Y view, or 200X for X and Y view
• Viewing Method : Dual cameras with 4.7 inch TFT color LCD monitor
• Operating Condition : 0 to 5,000 m above sea level, 0 to 95%RH and -10 to 50°C respectively
• Mechanical Proof Test : 1.96 to 2.25N
• Tube Heater : Built-in tube heater with 30 heating modes; auto-start function
• Tube Heating Time : Typical 23 seconds with FP-03 sleeve, 17 seconds with FP3 (40), 5-16 seconds with Fujikura micro sleeves, 15 seconds with slim 60 mm and 40 mm sleeves
• Protection Sleeve Length : 60 mm, 40 mm, micro
• Splice/Heat Cycles with Battery : Typical 200 cycles with power save functions activated
• Electrode Life : 5,000 Arc Discharges
• Power Supply : Auto voltage selection from 100 to 240 V AC or 10 to 15 V DC with ADC-18, 14.8  V DC with BTR-09 battery
• Terminals : USB 1.1 (USB-B type) for PC communication. Mini-DIN (6-pin) for HJS-02/03
• Wind Protection : Maximum wind velocity of 15 m/s (34 mph)
• Dimensions : 146 W x 159 D x 150 H (mm) / 5.75 W x 6.25 D x 5.9 H (inches)
• Weight : 2.5 kg (5.5 lbs) with AC adapter ADC-18; 2.7 kg (5.95 lbs) with BTR-09 battery
• جهت مشاوره و خرید با شماره های ما در تماس باشید
